Discontinued Products

These products are no longer being sold.

The AVFM 5.0 Area-Velocity Flow Meter measures both Level and Velocity to calculate flow in an open channel, partially full sewer pipes, and surcharged pipes without a flume or weir. Calibration is simple: enter the pipe diameter or channel dimensions and the AVFM 5.0 automatically computes and displays flow volume.

The AVFM 5.0 has been replaced by the AVFM 6.1 Area-Velocity Flow Meter, which offers enhanced performance and optional Modbus RTU Output.

AVFM 5.0
AVFM 5.0 - Discontinued
Installation & Instruction Manual
AVFM 5.0 - Discontinued
Engineering Specifications

The Blackbox blind non-isolated version was designed for anyone who needed a simple straight forward level indication. With no display, it was ideal for those applications where power was scarce and it could be programmed via a handheld calibrator or Blackbox PC Software.

The unit has now been replaced by the Blackbox 130 display version, which can be programmed via its integral keyboard and provides an output representative of volume.

Blackbox 130 (blind non-isolated version)
Blackbox 130 Blind Version - Discontinued
Datasheet
Blackbox 130 Blind Version - Discontinued
Installation & Instruction manual

The DFM 5.1 Doppler Flow Meter monitors the flow rate of dirty or aerated liquids including wastewater, chemicals, acids, slurries, abrasives, and viscous liquids. Recommended for full pipes and any fluid that contains solids or bubbles. The sensor is mounted on the outside of a plastic or metal pipe 12.7 mm (0.5 in) diameter or larger.

The DFM 5.1 has been replaced by the DFM 6.1 Doppler Flowmeter, which offers enhanced performance and now has as an option Modbus RTU or HART.

DFM 5.1
DFM 5.1 - Discontinued
Installation & Instruction Manual
DFM 5.1 - Discontinued
Engineering Specifications

Non-contacting, open channel flow measurement is difficult to get right, especially when there is an ever-increasing need for accurate and reliable flow readings. The DUET is a unique product to Pulsar Measurement and features a patented approach to addressing the issue of accuracy for non-contacting open channel flow measurement.

Both ultrasonic transducers fire together, continuously monitoring the phase difference of the echoes, and because the distance between the transducer faces is known and constant, the speed of sound is continuously updated in real-time for the process. Meaning the accuracy and stability of open channel flow measurement readings are exceptional.

The DUET transducer can be combined with the FlowCERT controller. The combined system is MCERTS Class 1 certified, meaning the open channel flow measurement readings from the DUET and FlowCERT meet the industry standard, so utilities across the globe can be confident in their flow measurement.

DUET Dual Channel Sensors
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
DUET
Datasheet
DUET
Installation & Instruction Manual
DUET
Technical Drawing (UNCONTROLLED COPIES)
MCERTS Certification
FlowCERT + DUET
Warranty
Pulsar Product Warranty

The Greyline OCF 5.0 uses a non-contacting ultrasonic sensor mounted over a flume or weir to measure flow. It is accurate, reliable, and verifiable. The separate, watertight electronics/display enclosure can be mounted within 150 m (500 ft) of the sensor. The OCF 5.0 continuously displays, totalizes, transmits and data logs open channel flow.

The Greyline OCF 5.0 Open Channel Flow Monitor has been replaced by the Greyline OCF 6.1 Open Channel Flow & Tank Level Meter, which offers expanded flume & weir selections or level tank monitoring, and it also has optional MODBUS RTU Output.

OCF 5.0
OCF 5.0 - Discontinued
Installation & Instruction Manual
OCF 5.0 - Discontinued
Engineering Specifications

The PDFM 5.1 Portable Doppler Flow Meter is a portable flow meter that clamps to the outside of a pipe to gain pipe flow measurement. The ultrasonic Doppler technology used by the PDFM 5.1 makes it perfect for use as a water flow meter, specifically for dirty or difficult liquids that contain bubbles or solids, like wastewater, slurries, sludge, chemicals, viscous liquids, and abrasives.

The PDFM 5.1 is ideal for evaluating system performance and can be installed, calibrated, and started up in minutes. Use this flow meter where a permanent flow meter is not required, or temporarily replace installed flow meters. Fast and easy to operate, the sensor mounts to the outside of a pipe in less than a minute, using the built-in keypad and calibration menu to set up the flowmeter for the application.

With its internal battery, the PDFM 5.1 will operate all day and recharge overnight. For continuous use, it can be powered by a supplied 110-240 V AC wall plug adaptor or use Sleep Mode to only wake up the meter to take a measurement periodically, extending battery life. A 300,000-point data logger is built into the unit.

Display units can be selected by the user, and the PDFM 5.1 Portable Doppler Flow Meter will display and totalize flow in gallons, liters, cubic feet, or cubic meters. If you change from one measurement system to another, the PDFM 5.1 will automatically and instantly calculate and covert the total flow display and totalizer. Calibrate to the pipe size using the keypad to enter the inside diameter.

The 4-20mA output featured on the unit allows you to use the PDFM 5.1 Portable Doppler Flow Meter in critical applications. Ideal applications for this ultrasonic flow meter, with a non-contacting clamp-on ultrasonic sensor include influent and effluent pipe flow, industrial pipe flows, irrigation flows, food and beverage manufacturers, pharmaceutical processes, and many more!

Gain a full overview of our pipe flow measurement solutions by contacting a member of our team today.

Gain a full overview of our pipe flow measurement solutions by contacting one of our team today.

PDFM 5.1
PDFM 5.1
PDFM 5.1
PDFM 5.1
Sand slurry measurement with PDFM 5.1
Stingray, PDFM, DFM
Portable flow meters solve flow rate discrepancies between pump station effluent and lagoon influent flow meters.
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
PDFM 5.1
Datasheet
PDFM 5.1
Installation & Instruction Manual
PDFM 5.1
Engineering Specifications
Greyline Logger
Greyline Logger Software
Greyline Logger
Software Brochure
Two Technologies for Flow
Doppler and Transit Time for non-invasive measurement of flow in full pipes.
Doppler for Fly Ash Slurry Flow
The limestone slurry is abrasive so in-line flowmeters are not practical. Non-contacting Doppler flowmeters can be used both on the fly ash slurry supply lines and on "used" or recirculated slurry.
Explosion Proof Enclosure
Datasheet
SCR Enclosure Sun Screen
Datasheet

The Greyline PTFM 1.0 Portable Transit-Time Flow Meter measures pipe flow with a clamp-on, non-contacting, ultrasonic sensor. Measuring the time it takes to transmit one ultrasonic sound from one sensor to the other. The Portable Transit-Time Flow Meter can be used for calibrations, troubleshooting, flow surveys, or as a temporary clamp-on flow meter to replace inline flowmeters. Causing no interruption to the process, no downtime, and no need to cut into a pipe, simply strap the transit-time sensors to the outside of the pipe from 50 mm to 1200 mm (2 in to 48 in) diameter.

The transit-time technology makes the PTFM ideal for clean liquid flow monitoring on applications such as treated water flow, effluent pipe flow, irrigation flow, and compliance with water abstraction licenses.

The PTFM 1.0 Portable Transit-Time Flow Meter can be mounted without interrupting operations and there is no obstruction or pressure drop. With no moving parts, there is little to no maintenance required with the PTFM 1.0, and the unit gives accurate and repeatable pipe flow readings for clean liquids in minutes.

The PTFM 1.0 has now been replaced by the upgraded PTFM 6.1 version which can be viewed here

PTFM 1.0
TTFM 6.1
Summerheights Golf Links Ontario, get efficient control over water pumped to sprinkler system
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
PTFM 1.0 - Discontinued
Datasheet
PTFM 1.0 - Discontinued
Installation & Instruction Manual
Greyline Logger
Greyline Logger Software
Greyline Logger
Software Brochure
Two Technologies for Flow
Doppler and Transit Time for non-invasive measurement of flow in full pipes.
Explosion Proof Enclosure
Datasheet
SCR Enclosure Sun Screen
Datasheet

The PulsarGuard 2001 sand sensor has been specifically designed for the Oil and Gas industry, using acoustic technology to detect sand / solids impact rate. The non-contacting sand-in-oil sensor is connected to the outside of the pipeline with a stainless steel band, meaning there is no need to break into the pipe or interrupt the operation. Using acoustic technology, it detects changes in the signature of flow within the pipe and converts it into a sand / solids impact rate. This makes it the ideal sensor to monitor well productivity and efficiency, detect blockages and/or foreign objects, and monitor the production of sand in oil and gas operations.

The PulsarGuard 2001 sand sensor MUST be used with the iSensys SandAlert monitor or the iSensys SandAlert portable units. The oil sensor is an intrinsically safe unit, ATEX approved to ATEX EEx ia IIC T4, and is made from 316 stainless steel with environmental protection to IP68. Its narrow frequency band makes the sensor highly resistant to interference from background noise, fluid flow, or gas flow.

For more information on our Sand in Oil measurement products, contact one of our friendly team today.

PulsarGuard 2001
PulsarGuard 2001
iSensys SandAlert
Portable case
PulsarGuard 2001
Product Brochure
ATEX PulsarGuard 2001
Ex ia Certificate
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
PulsarGuard 2001
Datasheet
PulsarGuard 2001
Installation & Instruction Manual
Warranty
Pulsar Product Warranty

The PulsarPoint 300 series provides effective management of material storage and flow, empty vessels, clogged or blocked chutes or conveyors, and provides prevention of overflows. The ideal applications for this product are usually found in food and beverage, animal feed, pharmaceutical, chemical, plastics, quarrying, power generation, cement, and other industrial-like industries. They are perfect for those applications that require accurate level measurement of solids.

The PulsarPoint 300 series uses a rotating paddle, the paddle's rotation is interrupted when the material reaches the paddle, causing a clutch to disengage the motor. This in turn actuates a relay allowing an alarm signal to be switched. The product is fully configurable and can be used to signify high, intermediate, or low-level material.

PulsarPoint 300 Series
(ALL) Pulsar Product Brochures
All brochures in one .zip folder

Specifically developed for sand monitoring in the oil and gas industry, the iSensys SandAlert monitor is a sand and particle monitor that is ideal wherever you need to keep wells producing efficiently. Sand production for oil and gas operators is an increasing problem and can cause catastrophic damage to well and rig equipment. The SandAlert provides robust, dependable sand monitoring data, so plant operators can be confident they are operating at the highest capacity possible.

Why Measure Sand in Oil?

Solids/sand production in oil and gas wells is a growing problem for oil and gas producers. Over the ages, there is a tendency to produce more solids through reservoir degradation. The challenge is not only to avoid solids/sand production but also to optimize well productivity, as even small quantities of solid particles in the well flow can cause significant pipe or valve damage.

When solids or sand are produced from a reservoir, the production rate is reduced, and maintenance costs go up. It also represents an environmental risk in the disposal of the solids. Produced solids/sand can never be ignored, and any well producing from an unconsolidated reservoir needs to have some sort of sand monitoring system in place, preferably monitoring in real-time.

The iSensys SandAlert monitor is designed to provide plant operators with the data they need on sand/solid production so that site and asset maintenance and management can become predictive and effective. The SandAlert system can measure sand production directly, without external or additional flow measurement.

When used with the PulsarGuard 2001 sand sensor, the unit can be positioned up to 1,000 m (3,280 ft) away from the application. An optional explosion-proof case is available for the SandAlert that converts the system into one that can be fully installed in a Zone 1 hazardous area. The graphical display shows a general overview of current signal information, a real-time sand impact trace graph, and an overview of relay settings.

To find out more about sand in oil monitoring, contact one of our friendly teams today.

SandAlert Monitor
iSensys SandAlert
Portable case
iSensys SandAlert
Monitor
Isensys SandAlert Monitor
Datasheet
iSensys SandAlert Monitor
Product Brochure
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
SandAlert Lite
Installation & Instruction Manual
SandAlert Wall Mount
Installation & Instruction Manual
Warranty
Pulsar Product Warranty

Sand monitoring in the oil and gas industry is absolutely paramount to keep wells producing efficiently and at capacity. Excessive solid production in the oil stream can cause catastrophic damage to well and rig equipment. The iSensys SandAlert Portable Sand Monitor has been designed to give oil and gas producers robust and dependable sand monitoring solutions. The Portable Sand Monitor is fitted into a rugged pelican case and is a complete kit including sensor, mounting strap, and 50 m extension lead, ideal for transporting between multiple sites.

When sand is produced from a reservoir, the production rate is reduced and maintenance costs go up, it also presents environmental risks with disposal of the solids. Produced sand enters the processing system and plant operators need to make sure that the process is capable of handling the sand/solids safely. An important aspect of sand management is reviewing erosion rates and removal issues.

The high-frequency, structure-borne acoustic signal generated by a sand impact on the wall of the pipe is detected by the PulsarGuard 2001 Sand Sensor. The acoustic signal is then converted and displayed on a graphic display on the iSensys Sand Alert Portable Sand Monitor.

For more information on our sand monitoring equipment, contact one of our friendly team today.

SandAlert Portable
PulsarGuard 2001
iSensys SandAlert
Portable case with Toolkit
iSensys SandAlert
Portable case
Isensys Sand Alert Portable Monitor
Datasheet
iSensys Sand Alert Portable Monitor
Product Brochure
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
SandAlert Lite
Installation & Instruction Manual
SandAlert Portable
Installation & Instruction Manual
PulsarGuard 2001
Installation & Instruction Manual
Warranty
Pulsar Product Warranty

The Greyline SLT 5.0 Level & Flow Monitor, displays, transmits, and totalizes wastewater flow through any flume or weir. Each SLT 5.0 includes a non-contacting ultrasonic sensor that mounts above the liquid being measured. Select flow mode for open channel applications or level mode for tank inventory, level control, and alarms.

The SLT 5.0 Level & Flow Monitor, has been replaced by the Greyline OCF 6.1 Open Channel Flow & Tank Level Meter, which offers expanded flume & weir selections or level tank monitoring and it also has optional MODBUS RTU or HART Output.

SLT 5.0
(ALL) Pulsar Product Brochures
All brochures in one .zip folder
SLT 5.0 - Discontinued
Installation & Instruction Manual
SLT 5.0 - Discontinued
Engineering Specifications
SCR Enclosure Sun Screen
Datasheet
SP1 Surge Protection
Datasheet
Warranty
Pulsar Product Warranty

The TTFM 1.0 Transit Time Flow Meter is designed for flow measurement of fairly clean, nonaerated liquids in full pipes. The clamp-on transducers can be mounted without system shutdown. There is no pressure drop and no obstruction.

The TTFM 1.0 has been replaced by the TTFM 6.1 Transit Time flowmeter, which now offers pipe sizes as low as 12.7 mm to 1.2 m (0.5 in to 48 in) and has optional Modbus RTU or HART.

TTFM 1.0
TTFM 1.0 - Discontinued
Installation & Instruction Manual
TTFM 1.0 - Discontinued
Engineering Specifications

Ultra 3 combines several full-function, world-beating ultrasonic level measurement instruments into one. Full control functions are available: open channel flow is calculated to BS ISO 1438 and 4359. Pump Control features are built into Ultra 3 and an extensive set of volume calculations and linearisation facilities are available for a tank or silo level measurement task.

The Ultra 3 has been replaced by the Ultra 4 which offers the extra relay and the ability to combine three specific duties in one compact and cost-effective control package.

Ultra 3
Ultra 3 - Discontinued
Datasheet
Ultra 3 - Discontinued
Installation & Instruction Manual
Ultra 3 - Discontinued
Installation & Instruction Manual - UL
Pulsar Certifications
